经历 MarkDown

Hello My Blog

博客搭建好了, 想想有点小激动

Posted by LeYe Hu on April 15, 2019

前言

一段时间的学习, 自身的不足愈加明显 通过写写博客, 放松的同时, 每日思考一下自己都做了些什么

正文

要写博客了, 使用MarkDown编写, 语法什么的还是需要了解的

本博客使用的是 Kramdown

Kramdown是一个完全由Ruby语言编写的Markdown解析器 在语法上Kramdown是Markdown的一个超集, 较Markdown而言, Kramdown语法更加严谨 但基本能很好的兼容Markdown语法, 有所差异的地方是高亮部分

以下语法参考官网文档

目前只记录一些常用的语法, 其余需要使用时在更新

转义序列

This \`is not a code\` span!
以下列出一些需要通过转义序列来原样显示的字符
\ backslash
. period
* asterisk
_ underscore
+ plus
- minus
= equal sign
` back tick
()[]{}<> left and right parens/brackets/braces/angle brackets
# hash
! bang
<< left guillemet
>> right guillemet
: colon
| pipe
" double quote
' single quote
$ dollar sign

句子与段落

  • 一般而言, 单独由空格或者Tab组成的行会被视为一行空白行, 多行连续的空白行会被视为一行空白行
  • 一个段落, 首行最多三个缩进, 其他行可以有任意缩进

    块的边界问题需要注意一下, 一般可以通过^EOF标记来标识块的结束

标题

标题部分Kramdown支持 Setext 和 atx 样式

这里我主要使用atx样式

  • 以#开头, #前不能有空格, 任意#(包括0)来结束
  • #个数表示标题级别, 最多六级
  • 中间标题首尾两端的空格会被删除
    # First level header
### Third level header ###
## Second level header ######

    First level header

    Third level header

    Second level header

  • 设置头部 ID *
     # Hello # {#id}

    Hello

段落引用

  • 使用>标记, >后的第一个空格字符无效
  • 支持换行(可以通过EOB标记分割 ^)
  • 可以与其他块级元素嵌套使用(包括他自己)
    > This is a paragraph inside
  a blockquote.
>
> > This is a nested paragraph
  that continues here
> and here
> > and here

    This is a paragraph inside a blockquote.

    This is a nested paragraph that continues here and here and here

代码块

  • 可以使用四个空格或者一个Tab来标识
  • 或者三个及以上~开头及结尾
    ~~~~~~~~
Here comes some code.
~~~~~~~~
  • 代码中如果使用了~可以如下使用
    ~~~~~~~~~~~~
~~~~~~~
code with tildes
~~~~~~~~
~~~~~~~~~~~~~~~~~~
  • 可以使用IAL( inline attribute list)来标记语言类型, 使用键值对的形式
    {: title="The blockquote title"}
{: #myid}
{: .language-ruby}  标记ruby语言, 影响高亮显示

    也可以这样

    ~~~ ruby
def what?
42
end
~~~

    def what?
42
end

与代码块有点类似的是Code Spans(不知道怎么翻译XX)

  • 使用 ` 包围, 可以将代码内联到句子中
    Use `<html>` tags for this.
This is a Ruby code fragment `x = Class.new`{:.language-ruby}

    Use <html> tags for this. This is a Ruby code fragment x = Class.new

  • 如果文本中包含`,就使用两个``包围
    Here is a literal `` ` `` backtick.
And here is `` `some` `` text (note the two spaces so that one is left
in the output!).

    Here is a literal ` backtick. And here is `some` text (note the two spaces so that one is left in the output!).

列表

  • 无序列表–*, +, - 后面接一个空格表示开始
  • 有序列表–数字. 后面接一个空格表示开始
* kram
+ down
- now
1. kram
2. down
3. now
  • kram
  • down
  • now
    1. kram
    2. down
    3. now
  • 可以内嵌使用, 使用方式一致
1. list 1 item 1
 2. list 1 item 2 (indent 1 space)
  3. list 1 item 3 (indent 2 spaces)
   4. list 1 item 4 (indent 3 spaces)
    5. lazy text belonging to above item 4
* list 1 item 1
  * nested list item 1(indent 2 space)
  * nested list item 2
* list 1 item 2
  * nested list item 1
  1. list 1 item 1
  2. list 1 item 2 (indent 1 space)
  3. list 1 item 3 (indent 2 spaces)
  4. list 1 item 4 (indent 3 spaces) 5. lazy text belonging to above item 4
    • list 1 item 1
      • nested list item 1(indent 2 space)
      • nested list item 2
    • list 1 item 2
      • nested list item 1

表格

  • 使用|符号进行表格单元格切分, 尾部的可以忽略
| First cell|Second cell|Third cell
| First | Second | Third |

First | Second | | Fourth |
First cell Second cell Third cell
First Second Third
First Second   Fourth
|-----------------+------------+-----------------+----------------|
| Default aligned |Left aligned| Center aligned  | Right aligned  |
|-----------------|:-----------|:---------------:|---------------:|
| First body part |Second cell | Third cell      | fourth cell    |
| Second line     |foo         | **strong**      | baz            |
| Third line      |quux        | baz             | bar            |
|-----------------+------------+-----------------+----------------|
| Second body     |            |                 |                |
| 2 line          |            |                 |                |
|=================+============+=================+================|
| Footer row      |            |                 |                |
|-----------------+------------+-----------------+----------------|
Default aligned Left aligned Center aligned Right aligned
First body part Second cell Third cell fourth cell
Second line foo strong baz
Third line quux baz bar
Second body
2 line
Footer row
  • 也可以这样写
|---
| Default aligned | Left aligned | Center aligned | Right aligned
|-|:-|:-:|-:
| First body part | Second cell | Third cell | fourth cell
| Second line |foo | **strong** | baz
| Third line |quux | baz | bar
|---
| Second body
| 2 line
|===
| Footer row
Default aligned Left aligned Center aligned Right aligned
First body part Second cell Third cell fourth cell
Second line foo strong baz
Third line quux baz bar
Second body
2 line
Footer row

水平线

  • 三个连续的*, -或者_
* * *
---
_ _ _ _
---------------

数学表达式

  • 两个$$包围, 使用需要符合LaTeX语法 (需要使用 MathJax 脚本渲染)
$$
\begin{align*}
  & \phi(x,y) = \phi \left(\sum_{i=1}^n x_ie_i, \sum_{j=1}^n y_je_j \right)
  = \sum_{i=1}^n \sum_{j=1}^n x_i y_j \phi(e_i, e_j) = \\
  & (x_1, \ldots, x_n) \left( \begin{array}{ccc}
      \phi(e_1, e_1) & \cdots & \phi(e_1, e_n) \\
      \vdots & \ddots & \vdots \\
      \phi(e_n, e_1) & \cdots & \phi(e_n, e_n)
    \end{array} \right)
  \left( \begin{array}{c}
      y_1 \\
      \vdots \\
      y_n
    \end{array} \right)
\end{align*}
$$
  • 内联使用
\$$ 5 + 5 $$

Html语句块

<div id="content"><div id="layers"><div id="layer1">
This is some text in the `layer1` div.
</div>
This is some text in the `layers` div.
</div></div>
This is a para outside the HTML block.
This is some text in the `layer1` div.
This is some text in the `layers` div.

This is a para outside the HTML block.

链接

  • 使用尖括号包围<>
Information can be found on the <http://example.com> homepage.
You can also mail me: <me.example@example.com>

Information can be found on the http://example.com homepage. You can also mail me: me.example@example.com

  • [文本](链接 “标题”)
This is [a link](http://rubyforge.org) to a page.
A [link](../test "local URI") can also have a title.
And [spaces](link with spaces.html)!

This is a link to a page. A link can also have a title. And spaces!

参考

The next paragraph contains a link and some text.
[Room 100]\: There you should find everything you need!
[Room 100]: link_to_room_100.html

The next paragraph contains a link and some text. [Room 100]: There you should find everything you need! [Room 100]: link_to_room_100.html


  • 和链接很像, 只需要在前面加入一个惊叹号, 也可以加入内联属性设置宽高
Here is an inline ![Cat](/kongfu-cat-blog/img/kongfu-cat.jpg){:height="36px" width="36px"}.
And here is a referenced ![Cat]

[Cat]: /kongfu-cat-blog/img/kongfu-cat.jpg
{: height="36px" width="36px"}

Here is an inline Cat. And here is a referenced Cat

强调

  • 使用*或_包围
  • 强调文本–斜体
  • 强强调文本–粗体
  • 没有更强的了:)
*some text*
_some text_
**some text**
__some text__

some text some text some text some text

脚注

  • [ ]内以^开头
  • 在[^ ]之前要有换行
This is some text.[^1]. Other text.[^footnote].

[^1]: Some *crazy* footnote definition.
[^footnote]:
    > Blockquotes can be in a footnote.

This is some text.1. Other text.2.

后记

还是不怎么习惯看英文资料, 写的想吐, 欧拉欧拉 XX 由于英文水平较渣, 可能还有不少翻译上的问题, 之后遇到在修改吧

— LeYe Hu 初记于 2019.04.15

  1. Some crazy footnote definition. ↩

  2. Blockquotes can be in a footnote.

    ↩
